德國倍福XTS線性傳輸系統

貝克霍夫的線性傳輸系統。兩種經過驗證的驅動原理-結合成一種新的驅動技術。隨著XTS(擴展傳輸系統)線性傳輸系統，貝克霍夫提出了一種驅動器解決方案，這是前所未有的解決方案-因為它結合了兩個***的驅動原理的優點，在一個單一的系統。在以前使用旋轉電機的可能性已經結束的地方，XTS增加了線性系統的優點。到目前為止，在純線性系統的使用范圍有限的地方，XTS補充了旋轉解決方案的好處。特殊需求需要特殊的解決方案，這就是為什么開發完全封裝的XTS衛生版本和XTS黑線來補充XTS標準的原因。

System properties	XTS Standard
Max. force	100 N at standstill
Continuous force	30 N (at ~30 °C temperature increase in the motor compared to mounting frame)
Speed	4 m/s @ 48 V DC supply
Acceleration	> 100 m/s? (without payload)
Positioning accuracy	<±0.15 mm @ 1.5 m/s possible within a straight module
Absolute accuracy	<±0.25 mm possible within a straight module
Repeatability	<±10 μm (standstill unidirectional)
Mover length	50 mm in direction of movement
Mover weight	approx. 410 g (complete mover without attachments)
Max. system length	> 100 m (dependent on computing power, no system limit)
Operating/storage temperature	-10…+40 °C/-25…+85 °C (for further information see documentation)
Protection class	motor modules: IP 65 (for further information see documentation)
Approvals/Markings	CE, UL
Vibration/shock resistance	conforms to EN 60068-2-6/EN 60068-2-27
EMC immunity/emission	conforms to EN 61000-6-2/EN 61000-6-4

Electrical data	XTS
Supply voltage	control voltage 24 V DC, power supply 48 V DC
Current consumption	power supply: 16 A nominal current
Power consumption 24 V DC	motor modules: 30 W/m (communication, electronics, position determination)
Length per feed	max. 3 m (voltage supply, EtherCAT)
Power consumption per mover	approx. 30 W @ 2 m/s constant speed

XTS products
AT20xx-0xxx	XTS motor module
AT901x-0050-0550	XTS mover
AT9xxx-xxxx	XTS guide rails
AT2000-xx00	XTS starter kits
TF5850-00pp	TC3 XTS Extension
